Product Description
Littelfuse Industrial Business Unit KLNR Series Fuse; Requires Holder; 200kA AC, 20kA DC; 8A;250 VAC;125 VDC; Fast Blow; Cartridge, Non-Standard
Cylindrical Fuse • Mounting Type: Requires Holder • Fuse Type: Cartridge • Current Rating (Amps): 8A • Voltage Rating - AC: 250 VAC • Voltage Rating - DC: 125 VDC • Response Time: Fast Blow • Class: RK1 • Breaking Capacity @ Rated Voltage: 200kA AC, 20kA DC • Package / Case: Cartridge, Non-Standard
Product Information
| Manufacturer | Littelfuse Industrial Business Unit |
| Product Category | Fuses |
| Product Sub Category | Cylindrical Fuse |
| Series | KLKR Series |
| Catalog Part Number | KLKR.300S |
| Ordering Part Number | KLKR.300TS |
Specifications
| Product Attribute | Attribute Value |
|---|---|
| Mounting Type | Requires Holder |
| Fuse Type | Cartridge |
| Current Rating (Amps) | 300mA |
| Voltage Rating - AC | 600 VAC |
| Voltage Rating - DC | 300 VDC |
| Response Time | Fast Blow |
| Applications | Electrical, Industrial |
| Class | CC |
| Approval Agency | CE, CSA, UL |
| Breaking Capacity @ Rated Voltage | 200kA AC, 20kA DC |
| Package / Case | 5AG, 10mm x 38mm (Midget) |
Series Features
Class CC Fuses KLKR Series 600 V ac • 300 V dc • Fast-Acting • 1⁄10 – 30 A
Series DescriptionThe KLKR Series fast-acting fuses are designed for general-purpose branch circuit protection. Their compact size, fast-acting overload response, and current-limiting design make them ideal for use in OEM equipment and control panels. They are widely used in lighting circuits and control transformer circuits where a fast overload response is required. These KLKR Series Class CC fuses have rejection features that prevent substitution of lower rated fuses. Due to their compact size, these fuses provide superior branch circuit protection in a fraction of the space required by other fuse classes. The KLKR Series fuses comply with UL and CSA standards.
- Fast-acting: Provides protection for equipment requiring fast overload protection
- Current-limiting: Reduces damage caused by heating and magnetic effects of short-circuit currents
- Rejection capability: Prevents use of fuses with lower interrupting ratings or voltage when used with corresponding fuse holders
- 200,000 AIR: Smallest 600 V, 200,000 A fuse approved for branch circuit protection
Control circuits, General loads, Branch circuit protection, Solid-state components
