To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | LITTELFUSE |
| Manufacturer Product Number | 0232003.MXF34P |
| Description | Glass Fuse; 3 A; Medium-Acting; 5x20mm; Pigtail; Bulk 1000 F34; DENAN (METI); 250 VAC |
| Datasheet | Download Datasheet |
The Littelfuse 0232003.MXF34P is a 3 A glass fuse in the 5 x 20 mm size, with axial leads (pigtails), rated 250 VAC.
The axial leads solder straight to a board or terminal strip, with no holder.
Breaking capacity: 10 kA @ 125 VAC. Opening times, as a percentage of the rated current: 130%: min. 1 h; 160%: max. 1 h; 200%: max. 2 min. Typical cold resistance 0.0226 Ω, melting I²t 17.19000 A²s. It operates from -60 to +125 °C.
Construction: glass body; nickel–plated brass end caps.
It is PSE, KC and CE. Standards: DENAN (METI).
| Category | |
| Manufacturer | LITTELFUSE |
| Model | 232 |
