| Manufacturer | LITTELFUSE |
| Manufacturer Product Number | FLSR040 |
| Description | Industrial Fuse; 40A; Class RK5; Dual Elem; 27.0x139.7; 600 VAC / 300 VDC |
| Datasheet | Download Datasheet |
The Littelfuse FLSR040 is a 40 A dual-element time-delay UL Class RK5 fuse, rated 600 VAC / 300 VDC.
Class RK5 is a current-limiting branch-circuit fuse whose rejection groove fits Class R holders; dual-element types ride through motor starting current.
Interrupting rating: 200 kA @ 600 VAC (300 kA Littelfuse self-certified); 20 kA @ 300 VDC.
Construction: 27.0 x 139.7 mm diameter x length; ferrule with rejection groove.
It is UL Listed and CSA certified (UL file E81895). Standards: UL 248-12.
| Category | |
| Manufacturer | LITTELFUSE |
| Model | FLSR |
