Product Description
Kycon KLDX-SMT-0202 Series DC Power Jack; Male; 2.00mm ID, 5.50mm OD; Surface Mount, RA; Thru Hole
DC Power Jack • Gender: Male • Industry Recognized Mating Diameter: 2.00mm ID (0.079"), 5.50mm OD (0.217") • Number of Positions/Contacts: 2 Conductors, 3 Contacts • Internal Switch(s): Single Switch, Normally Closed • Mounting Type: Surface Mount, Right Angle; Through Hole • Shielding: Unshielded
Product Information
| Manufacturer | Kycon |
| Product Category | Connector, Interconnect |
| Product Sub Category | DC Power Jack |
| Series | KLDX-SMT-0202 Series |
Specifications
| Product Attribute | Attribute Value |
|---|---|
| Connector Type | Jack |
| Gender | Male |
| Industry Recognized Mating Diameter | 2.00mm ID (0.079"), 5.50mm OD (0.217") |
| Actual Diameter | 0.079" (2.00mm ID), 0.248" (6.30mm OD) |
| Number of Positions/Contacts | 2 Conductors, 3 Contacts |
| Internal Switch(s) | Single Switch, Normally Closed |
| Mounting Type | Surface Mount, Right Angle; Through Hole |
| Termination | Solder |
| Shielding | Unshielded |
| Features | Solder Retention |
| Voltage - Rated | 24VDC |
| Current Rating (Amps) | 3.5 A |
| Material Flammability Rating | UL94 V-0 |
| Operating Temperature | -25°C ~ 85°C |
