Product Description
Kycon KF22X Series D-Sub; Plug, Male Pins; 25 Pos;2 Rows; Thru Hole, RA; Housing/Shell (4-40)
D-Subminiature • Connector Type: Plug, Male Pins • Number of Positions: 25 • Number of Rows: 2 • Mounting Type: Through Hole, Right Angle • Flange Feature: Housing/Shell (4-40) • Backset Spacing: 0.318" (8.08mm)
Product Information
| Manufacturer | Kycon |
| Product Category | Connector, Interconnect |
| Product Sub Category | D-Subminiature |
| Series | KF22X Series |
Specifications
| Product Attribute | Attribute Value |
|---|---|
| Connector Style | D-Sub |
| Connector Type | Plug, Male Pins |
| Number of Positions | 25 |
| Number of Rows | 2 |
| Mounting Type | Through Hole, Right Angle |
| Shell Size, Connector Layout | 3 (DB, B) |
| Contact Type | Signal |
| Flange Feature | Housing/Shell (4-40) |
| Termination | Solder |
| Shell Material, Finish | Steel, Nickel Plated |
| Contact Finish | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Material Flammability Rating | UL94 V-0 |
| Current Rating (Amps) | 2A |
| Backset Spacing | 0.318" (8.08mm) |
| Features | Board Lock, Grounding Indents |
Series Features
KF22X Series
Series DescriptionD-SUBMINIATURE CONNECTORS: Right Angle PCB Mount 0.318" Footprint with Ferrite
