Product Description
Kycon K86X Series D-Sub; Receptacle, Female Skt; 62 Pos;3 Rows; Through Hole; BdSd(4-40);MatSd,F ScwLk(4-40)
D-Subminiature • Connector Type: Receptacle, Female Sockets • Number of Positions: 62 • Number of Rows: 3 • Mounting Type: Through Hole • Flange Feature: Board Side (4-40); Mating Side, Female Screwlock (4-40)
Product Information
| Manufacturer | Kycon |
| Product Category | Connector, Interconnect |
| Product Sub Category | D-Subminiature |
| Series | K86X Series |
Specifications
| Product Attribute | Attribute Value |
|---|---|
| Connector Style | D-Sub, High Density |
| Connector Type | Receptacle, Female Sockets |
| Number of Positions | 62 |
| Number of Rows | 3 |
| Mounting Type | Through Hole |
| Shell Size, Connector Layout | 4 (DC, C) High Density |
| Contact Type | Signal |
| Flange Feature | Board Side (4-40); Mating Side, Female Screwlock (4-40) |
| Termination | Solder Cup |
| Shell Material, Finish | Steel, Nickel Plated |
| Contact Finish | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Material Flammability Rating | UL94 V-0 |
| Current Rating (Amps) | 1.5A |
| Features | - |
Series Features
D-SUBMINIATURE CONNECTORS: K86X Series
Series DescriptionHigh Density Vertical PCB Mount and Solder Cup
