To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Kycon |
| Manufacturer Product Number | K22XHT-C37S-N30 |
| Description | D-Sub Connector; D-Sub; 37-pos; Receptacle, Female Sockets; Through Hole, Right Angle |
| Datasheet | Download Datasheet |
The Kycon K22XHT-C37S-N30 is a D-Sub receptacle rated 2 A.
It has Through Hole or Right Angle mounting.
It has a board lock.
| Category | |
| Manufacturer | Kycon |
| Gender | Receptacle, Female Sockets |
| Connector Style | D-Sub |
| Number of Positions | 37 |
| Number of Rows | 2 |
| Mounting Type | Through Hole, Right Angle |
| Contact Type | Signal |
| Flange Feature | Housing/Shell (4-40) |
| Termination | Solder |
| Shell Material, Finish | Steel, Nickel Plated |
| Contact Finish | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Flammability Rating | UL94 V-0 |
| Shell Size, Connector Layout | 4 (DC, C) |
| Current Rating (A) | 2 |
| Features | Board Lock |
| Backset Spacing | 0.318" (8.08mm) |
