To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | IDEC |
| Manufacturer Product Number | ASW31L11-203 |
| Description | Selector Switch; Lever; 3-pos; Spring return from right; 1NO-1NC |
| Datasheet | Download Datasheet |
The IDEC ASW31L11-203 is a 22 mm 3-position lever selector switch from IDEC's TW metal-bezel series: spring return from right, 1NO-1NC contacts.
It has a lever operator and a chrome-plated metal octagonal bezel.
Its snap-on contact blocks are rated 10 A thermal (AC-15 A600, DC-13 P600) with silver contacts and M3.5 screw terminals. It mounts in a 22.3 mm panel hole. The panel front is IP65 and NEMA 4X. Minimum mechanical life 500,000 operations. It operates from -25 to +50 °C. Contact circuit code 203.
| Category | |
| Manufacturer | IDEC |
| Selector Type | Lever |
| Number of Positions | 3 |
| Switch Function | Spring return from right |
| Circuit | 1NO-1NC |
| Current Rating | 10A |
| Contact Material | Silver |
| Illumination | Non-Illuminated |
| Bezel Material | Metal (chrome-plated) |
| Panel Cutout | Circular - 22.3mm Dia. |
| Mounting Type | Panel Mount, Front |
| Termination Style | Screw Terminal (M3.5) |
| Ingress Protection | IP65 (panel front) |
| NEMA Type Rating | 4X |
| Mechanical Life | 500,000 cycles |
| Operating Temperature (°C) | -25...+50 |
| Features | Contact circuit code 203 |
| Bezel Shape | Octagonal |
