To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | IDEC |
| Manufacturer Product Number | RU42S-M-D24 |
| Description | Power Relay; 4C 4PDT; 3 A; 24VDC; Non Latching; Socketable; Plug In |
| Datasheet | Download Datasheet |
The IDEC RU42S-M-D24 is a power relay with 4C 4PDT contacts, rated 3 A and switching up to 250V AC, 30V DC, driven by a 24VDC coil and drawing 44.7 mA.
It has Socketable mounting and Plug In terminals, contacts in AgNi (Gold Clad) and is supplied with bifurcated contacts, lighted indicator, mechanical indicator, momentary lever.
| Category | |
| Manufacturer | IDEC |
| Mounting Type | Socketable |
| Coil Voltage | 24VDC |
| Contact Configuration | 4C 4PDT |
| Contact Rating (A) | 3 |
| Switching Voltage | 250V AC, 30V DC |
| Contact Material | AgNi (Gold Clad) |
| Coil Current (mA) | 44.7 |
| Coil Resistance (ohm) | 605 |
| Coil Type | Non Latching |
| Termination Style | Plug In |
| Must Operate Voltage | 19.2 V |
| Must Drop-Out Voltage | 2.4 V |
| Features | Bifurcated Contacts, Lighted Indicator, Mechanical Indicator, Momentary Lever |
| Number of Poles | 4 |
| Approvals | UL Recognized, CSA, TÜV, CE |
| Operate Time (ms) | 20 |
| Release Time (ms) | 20 |
| Operating Temperature (°C) | -55...+60 |
| Rated Load AC1 (VA) | 750 |
| Mechanical Life (cycles) | 50,000,000 |
