Product Description
| This product has been Discontinued |
Description: Logic Controllers • LCD Screen: Yes • Rated Power Voltage: 24V DC • Allowable Voltage Range: 20.4 to 28.8V DC (Including ripple voltage) • Rated Power Frequency: - • Maximum Power Consumption: 6.0W • Program Capacity: 47,400 bytes (11,850 steps) • Input Points: 30 • Digital Input (Terminal No.): 22 (I0 to I7, I10 to I17, I20 to I25) • Shared Analog Input (Terminal No.): 8 (I26, I27, I30 to I35) • Output Points: 18 • 10A Relay Output (Terminal No.): - • 2A Relay Output (Terminal No.) : - • Transistor Output (Terminal No.): 18 (Q0 to Q7, Q10 to Q17, Q20, Q21)
| Product Information | Resources |
|
|
| Specifications |
| Product Attribute | Attribute Value |
| LCD Screen | Yes |
| Rated Power Voltage | 24V DC |
| Allowable Voltage Range | 20.4 to 28.8V DC (Including ripple voltage) |
| Rated Power Frequency | - |
| Maximum Power Consumption | 6.0W |
| Program Capacity | 47,400 bytes (11,850 steps) |
| Input Points | 30 |
| Digital Input (Terminal No.) | 22 (I0 to I7, I10 to I17, I20 to I25) |
| Shared Analog Input (Terminal No.) | 8 (I26, I27, I30 to I35) |
| Output Points | 18 |
| 10A Relay Output (Terminal No.) | - |
| 2A Relay Output (Terminal No.) | - |
| Transistor Output (Terminal No.) | 18 (Q0 to Q7, Q10 to Q17, Q20, Q21) |
| User Program Storage | Flash ROM (10,000 rewriting life) |
| RAM | Backup data: Internal relay, shift register, counter current value, data register, clock data (year, month, and day) |
| Backup Duration | Approx. 30 days (typical) at 25°C after backup battery fully charge |
| Battery | Lithium |
| Charging Time | Approx. 15 hours for charging from 0% to 90% of full charge |
| Battery Life | 5 years |
| Replaceability | Not possible |
| Clock Function | Clock accuracy: ±30 sec/month (typical) at 25°C |
| Control System | Stored program system |
| Operating Temperature | 0 to +55°C (operating ambient temperature) |
| Storage Temperature | 25 to +70°C (no freezing) |
| Series Features |
| FT1A Series - 48 I/O |
| Series Description: |
|
