To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | IDEC |
| Manufacturer Product Number | RC2V-C-D48 |
| Description | Power Relay; 2C DPDT; 8 A; 48VDC; Non Latching; Through Hole; PC Pin |
| Datasheet | Download Datasheet |
The IDEC RC2V-C-D48 is a power relay with 2C DPDT contacts, rated 8 A and switching up to 400V AC, 300V DC, driven by a 48VDC coil and drawing 11 mA.
It has Through Hole mounting and PC Pin terminals and contacts in AgSnO2 (Gold Plated).
| Category | |
| Manufacturer | IDEC |
| Mounting Type | Through Hole |
| Coil Voltage | 48VDC |
| Contact Configuration | 2C DPDT |
| Contact Rating (A) | 8 |
| Switching Voltage | 400V AC, 300V DC |
| Contact Material | AgSnO2 (Gold Plated) |
| Coil Current (mA) | 11 |
| Coil Resistance (ohm) | 4400 |
| Coil Type | Non Latching |
| Termination Style | PC Pin |
| Must Operate Voltage | 33.6 V |
| Must Drop-Out Voltage | 4.8 V |
| Seal Rating | Sealed - Flux Protection |
| Number of Poles | 2 |
| Approvals | UL/c-UL Recognized, VDE, CQC, CE, UKCA |
| Operate Time (ms) | 15 |
| Release Time (ms) | 5 |
| Operating Temperature (°C) | -40...+75 |
| Rated Load AC1 (VA) | 2000 |
| Mechanical Life (cycles) | 20,000,000 |
