To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | IDEC |
| Manufacturer Product Number | RC1V-C-D5 |
| Description | Power Relay; 1C SPDT; 12 A; 5VDC; Non Latching; Through Hole; PC Pin |
| Datasheet | Download Datasheet |
The IDEC RC1V-C-D5 is a power relay with 1C SPDT contacts, rated 12 A and switching up to 440V AC, 300V DC, driven by a 5VDC coil and drawing 81 mA.
It has Through Hole mounting and PC Pin terminals and contacts in AgSnO2.
| Category | |
| Manufacturer | IDEC |
| Mounting Type | Through Hole |
| Coil Voltage | 5VDC |
| Contact Configuration | 1C SPDT |
| Contact Rating (A) | 12 |
| Switching Voltage | 440V AC, 300V DC |
| Contact Material | AgSnO2 |
| Coil Current (mA) | 81 |
| Coil Resistance (ohm) | 62 |
| Coil Type | Non Latching |
| Termination Style | PC Pin |
| Must Operate Voltage | 3.5 V |
| Must Drop-Out Voltage | 0.5 V |
| Seal Rating | Sealed - Flux Protection |
| Number of Poles | 1 |
| Approvals | UL/c-UL Recognized, VDE, CQC, CE, UKCA |
| Operate Time (ms) | 15 |
| Release Time (ms) | 5 |
| Operating Temperature (°C) | -40...+85 |
| Rated Load AC1 (VA) | 3000 |
| Mechanical Life | 20,000,000 cycles (100,000 cycles) |
