To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
Photo shows the green version; this part has an amber lens.
| Manufacturer | IDEC |
| Manufacturer Product Number | HW4P-2FQD-A-120V |
| Description | Pilot Light; LED, Amber; 100/120V AC/DC; Circular - 22.3mm Dia. |
| Datasheet | Download Datasheet |
The IDEC HW4P-2FQD-A-120V is a 22 mm HW amber pilot light with a round dome lens, for 100/120V AC/DC.
It uses a amber LED lamp (BA9S/13 base); lamp life is approx. 100,000 hours to 50% brightness. It mounts in a 22.3 mm panel hole. The front is IP65 and UL Type 4X; the terminals are finger-safe (IP20). It operates from -25 to +50 °C.
| Category | |
| Manufacturer | IDEC |
| Illumination Color | LED, Amber |
| Illumination Voltage | 100/120V AC/DC |
| Lens Style | Round Dome |
| Lamp Base | BA9S/13 |
| Panel Cutout | Circular - 22.3mm Dia. |
| Features | LED lamp life approx. 100,000 h (to 50% brightness) |
| Termination Style | Screw Terminal |
| Ingress Protection | IP65 (panel front), IP20 (terminals) |
| NEMA Type Rating | 4X |
| Operating Temperature | -25...+50 (-40...+80) |
| Mounting Type | Panel Mount, Front |
