To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
Photo shows the green version; this part has a white lens.
| Manufacturer | IDEC |
| Manufacturer Product Number | HW4P-2FM4D-W |
| Description | Pilot Light; 240V AC (transformer); Circular - 22.3mm Dia. |
| Datasheet | Download Datasheet |
The IDEC HW4P-2FM4D-W is a 22 mm HW white pilot light with a round dome lens, for 240V AC (transformer).
Lamp base: BA9S/13. It mounts in a 22.3 mm panel hole. The front is IP65 and UL Type 4X; the terminals are finger-safe (IP20). It operates from -25 to +50 °C.
| Category | |
| Manufacturer | IDEC |
| Illumination Voltage | 240V AC (transformer) |
| Color | White |
| Lens Style | Round Dome |
| Lamp Base | BA9S/13 |
| Panel Cutout | Circular - 22.3mm Dia. |
| Termination Style | Screw Terminal |
| Ingress Protection | IP65 (panel front), IP20 (terminals) |
| NEMA Type Rating | 4X |
| Operating Temperature | -25...+50 (-40...+80) |
| Mounting Type | Panel Mount, Front |
