To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Hammond |
| Manufacturer Product Number | 1490G10 |
| Description | Pushbutton Enclosure; 10; 30.5 mm; NEMA 12; 13x7.25x6.75 in; Mild Steel |
| Datasheet | Download Datasheet |
| Drawing | Download Dimensional Drawing |
The Hammond Manufacturing 1490G10 is a compact 13 x 7.25 x 6.75 in NEMA 12 pushbutton enclosure, formed from 14 gauge mild steel and finished in ANSI 61 Gray.
| Category | |
| Manufacturer | Hammond |
| Holes | 10 |
| Button Size | 30.5 mm |
| Material | Mild Steel |
| NEMA Type Rating | 12 |
| IP Rating | IP54 |
| Enclosure Height | 7.25 in (184 mm) |
| Enclosure Width | 13.00 in (330 mm) |
| Enclosure Depth | 6.75 in (171 mm) |
| Size | 13 x 7.25 x 6.75 in (330 x 184 x 171 mm) (L x W x H) |
| Panel Included | Yes |
| Body Gauge | 14 |
| Finish | Cover and enclosure are phosphatized and finished in ANSI 61 gray powder coating. |
| Color | ANSI 61 Gray |
| Standards | UL 508A Type 12 and 13, CSA Type 12 and 13 |
