Product Description
Description: Power Transformers • Type: Laminated Core • Voltage - Primary: 115V • Voltage - Secondary (Full Load): Parallel 5V, Series 10V • Current - Output (Max): Parallel 2.4A, Series 1.2A • Primary Winding(s): Single • Secondary Winding(s): Dual • Center Tap: No • Power - Max: 12VA • Mounting Type: Through Hole • : PC Pin
| Product Information | Resources |
|
|
RoHS Compliant| Specifications |
| Product Attribute | Attribute Value |
| Type | Laminated Core |
| Voltage - Primary | 115V |
| Voltage - Secondary (Full Load) | Parallel 5V, Series 10V |
| Current - Output (Max) | Parallel 2.4A, Series 1.2A |
| Primary Winding(s) | Single |
| Secondary Winding(s) | Dual |
| Center Tap | No |
| Power - Max | 12VA |
| Mounting Type | Through Hole |
| Termination Style | PC Pin |
| Size / Dimension | 47.63mm L x 39.67mm W |
| Height - Seated (Max) | 38.10mm |
| Voltage - Isolation | 2500Vrms |
| Weight | 0.7 lb (317.51 g) |
| Series Features |
| Low Voltage PCB Mount - Low Profile - 1.1 VA to 36 VA 162-164 Series |
