To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Finder |
| Manufacturer Product Number | 20.23.8.048.0000 |
| Description | Step Relay; NC → NO; 1A1B SPST-NO/SPST-NC; 16 A; 48V AC; AgNi |
| Datasheet | Download Datasheet |
The Finder 20.23.8.048.0000 is a 17.4 mm step relay with 1A1B SPST-NO/SPST-NC contacts and rated 16 A, driven by a 48V AC coil.
Each pulse on its coil moves the contacts one step through a 2-step sequence: NC contact closed, then NO contact closed.
Up to 15 illuminated push-buttons can drive it through module 026.00.
It has DIN Rail mounting and box clamp terminals, contacts in AgNi and is supplied with test button with mechanical indicator.
| Category | |
| Manufacturer | Finder |
| Model | 20.23 |
