Product Description
The Finder 20.22.9.110.0000 is a 17.4 mm step relay with 2A DPST-NO contacts and rated 16 A, driven by a 110V DC coil.
Each pulse on its coil moves the contacts one step through a 2-step sequence: both contacts open, then both contacts closed.
Up to 15 illuminated push-buttons can drive it through module 026.00.
It has DIN Rail mounting and box clamp terminals, contacts in AgNi and is supplied with test button with mechanical indicator.
Product Videos
Custom Field
product_attributes_title_07 Contact Material
product_attributes_value_07 AgNi
product_attributes_title_08 Maximum Peak Current (A)
product_attributes_value_08 30
product_attributes_title_09 Coil Operating Range
product_attributes_value_09 99...121 V (47 mA at nominal)
product_attributes_title_10 Coil Power
product_attributes_value_10 6.5 VA / 5 W
product_attributes_title_11 Impulse Duration
product_attributes_value_11 0.1 s min, 1 h max (EN 60669)
product_attributes_title_12 Features
product_attributes_value_12 Test button with mechanical indicator
product_attributes_title_13 Illuminated Push-Buttons
product_attributes_value_13 Up to 15, with module 026.00
product_attributes_title_14 Mechanical Life
product_attributes_value_14 300,000 cycles (100,000 cycles)
product_attributes_title_15 Module Width (mm)
product_attributes_value_15 17.4
product_attributes_title_16 Mounting Type
product_attributes_value_16 DIN Rail
product_attributes_title_17 Termination Style
product_attributes_value_17 Box Clamp Terminal
product_attributes_title_18 Insulation Coil-Contacts
product_attributes_value_18 4 kV (1.2/50 µs), 4000 V AC
product_attributes_title_19 Power Dissipation
product_attributes_value_19 2.6 W
product_attributes_title_20 Operating Temperature (°C)
product_attributes_value_20 -40...+40
product_attributes_title_21 Approvals
product_attributes_value_21 CE, UL Recognized, IMQ, RINA, Lloyd's Register, EAC
