Product Description
Description: Solid State Relay • Mounting Type: Chassis Mount • Contact Configuration: 1A SPST-NO • Output Type: AC, Zero Cross • Voltage - Input: 24VDC • Voltage - Load: 24 V ~ 660 V • Load Current: 60 A • No. of poles: 1 phase • Terminals arrangement: Relay style (input and output on opposite sides)
| Product Information | Resources |
|
|
RoHS Compliant| Specifications |
| Product Attribute | Attribute Value |
| Mounting Type | Chassis Mount |
| Contact Configuration | 1A SPST-NO |
| Output Type | AC, Zero Cross |
| Voltage - Input | 24VDC |
| Voltage - Load | 24 V ~ 660 V |
| Load Current | 60 A |
| No. of poles | 1 phase |
| Terminals arrangement | Relay style (input and output on opposite sides) |
| Series Features |
| TYPE 77.D1 - HOCKEY PUCK SOLID STATE RELAY |
|
