To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Finder |
| Manufacturer Product Number | 77.11.8.230.8250 |
| Description | Solid State Relay; 15 A - 230 V AC; 1A SPST-NO; 230VAC; Zero-Crossing; Relay |
| Datasheet | Download Datasheet |
The Finder 77.11.8.230.8250 is a 22.5 mm modular solid state relay with 1A SPST-NO output, rated 15 A at 230 V AC and switching 19 to 305 V AC, driven by a 230VAC input and drawing 25 mA.
Its TRIAC output switches on at the zero crossing, which suits lamps, heaters and solenoids and keeps lamp inrush down.
It carries a lamp rating of 4000 W incandescent/halogen, 3000 W LED, 3000 W CFL at 230 V.
Its terminals are relay style, with input and output on opposite sides.
It has DIN Rail mounting and box clamp terminals.
| Category | |
| Manufacturer | Finder |
| Model | 77.11 |
| Output Technology | TRIAC |
| Switch-On Mode | Zero-Crossing |
| Output Rating | 15 A - 230 V AC |
| Contact Configuration | 1A SPST-NO |
| Switching Voltage | 19…305 V AC |
| Output Type | AC |
| Maximum Peak Current (A) | 400 |
| Lamp Rating | 4000 W incandescent/halogen, 3000 W LED, 3000 W CFL at 230 V |
| Input Voltage | 230VAC |
| Input Current (mA) | 25 |
| Input Version | AC (50/60 Hz) |
| Input Operating Range | 40…280 V |
| Must Drop-Out Voltage | 6 V |
| Rated Power | 7.5/0.9 VA/W |
| On-State Voltage Drop (V) | 1.55 |
| Operate/Release Time | <10/<30 ms |
| Electrical Life (cycles) | 10,000,000 |
| Termination Style | Box Clamp Terminal |
| Mounting Type | DIN Rail |
| Module Width (mm) | 22.5 |
| Protection Category | IP 20 |
| Operating Temperature (°C) | -20…+80 |
| Approvals | CE, cULus, EAC |
