To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Finder |
| Manufacturer Product Number | 77.01.9.024.9024 |
| Description | Solid State Relay; 15 A - 24 V DC; 1A SPST-NO; 24VDC; Modular SSR |
| Datasheet | Download Datasheet |
The Finder 77.01.9.024.9024 is a 17.5 mm modular solid state relay with 1A SPST-NO output, rated 15 A at 24 V DC and switching 16 to 32 V DC, driven by a 24VDC input and drawing 18 mA.
Its MOSFET output is short-circuit protected.
It has DIN Rail mounting and box clamp terminals.
| Category | |
| Manufacturer | Finder |
| Model | 77.01 |
| Output Technology | MOSFET |
| Output Rating | 15 A - 24 V DC |
| Contact Configuration | 1A SPST-NO |
| Switching Voltage | 16…32 V DC |
| Output Type | DC |
| Maximum Peak Current (A) | 160 |
| Input Voltage | 24VDC |
| Input Current (mA) | 18 |
| Input Version | DC |
| Input Operating Range | 4…32 V |
| Must Drop-Out Voltage | 3 V |
| Rated Power | 0.4 W |
| On-State Voltage Drop (V) | 0.06 |
| Operate/Release Time | 0.05/2 ms |
| Electrical Life (cycles) | 10,000,000 |
| Termination Style | Box Clamp Terminal |
| Mounting Type | DIN Rail |
| Module Width (mm) | 17.5 |
| Protection Category | IP 20 |
| Operating Temperature (°C) | -20…+70 |
| Approvals | CE, cULus, EAC |
