Product Description
Description: Solid State Relay • Mounting Type: DIN Rail • Contact Configuration: 1A SPST-NO • Output Type: AC • Voltage - Input: 24VDC • Voltage - Load: 12 V ~ 275 V • Load Current: 2 A • Termination Style: Screw Terminal
| Product Information | | Resources |
| Manufacturer | Finder | | Product Category | Relay | | Product Sub Category | Solid State Relay | | Series | 39 Series | | Model | Type 39.30 |
| | |
Product Attribute
| Attribute Value
|
| Mounting Type | DIN Rail |
| Contact Configuration | 1A SPST-NO |
| Output Type | AC |
| Voltage - Input | 24VDC |
| Voltage - Load | 12 V ~ 275 V |
| Load Current | 2 A |
| Termination Style | Screw Terminal |
| Operating Temperature | -20°C ~ 55°C |
| Package / Case | Module |
| Approval Agency | CE, cURus, EAC |
| TYPE 39.30 - MASTERINTERFACE – MASTERPLUS SSR RELAY INTERFACE MODULE |
| Series Description: Type 39.30 MasterPLUS SSR Relay Interface Modules – SSR, solid state relay 0.1, 2 or 6 A, input supply 24 – 125 V AC/DC from 6 to 220 V DC and 230 V AC, 24… 240 V AC/DC, 1 contact, 6.2 mm wide, designed for interfacing with PLC systems. Screw terminals. 3 |
- Accepts the Type 093.63, 093.63.0.024, 093.63.8.230 fuse holder modules (for 5 x 20 mm fuses) which allows protection of the output circuit saving space
- Common connection of terminals A1, A2 and 11 with jumper link
- UL Listing (relay/socket/jumper link)
- Version available with Push-In terminals (Type 39.60).
- Version available with screw terminals and residual current suppression circuit, power supply 125 V AC/DC and 230 V AC (Type 39.30.3).
- Version available with Push-In terminals and residual current suppression circuit, power supply 125 V AC/DC and 230 V AC (Type 39.60.3).
|
RoHS Compliant
