To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Finder |
| Manufacturer Product Number | 38.81.3.125.9024 |
| Description | Solid State Relay; 6 A - 24 V DC; 1A SPST-NO; 125VAC/DC; Solid State 6.2 mm |
| Datasheet | Download Datasheet |
The Finder 38.81.3.125.9024 is a 6.2 mm Solid State 6.2 mm solid state relay with 1A SPST-NO output, rated 6 A at 24 V DC and switching 1.5 to 33 V DC, driven by a 125VAC/DC input and drawing 8 mA.
It has DIN Rail mounting and screw terminals.
| Category | |
| Manufacturer | Finder |
| Model | 38.81 |
| Output Technology | Solid State Relay |
| Output Rating | 6 A - 24 V DC |
| Contact Configuration | 1A SPST-NO |
| Switching Voltage | 1.5…33 V DC |
| Output Type | DC |
| Maximum Peak Current (A) | 50 |
| Input Voltage | 125VAC/DC |
| Input Current (mA) | 8 |
| Input Version | Leakage current suppression |
| Input Operating Range | 94…138 V |
| Rated Power | 1/1 VA/W |
| On-State Voltage Drop (V) | 0.4 |
| Operate/Release Time | 0.2/0.6 ms |
| Termination Style | Screw Terminal |
| Mounting Type | DIN Rail |
| Module Width (mm) | 6.2 |
| Protection Category | IP 20 |
| Operating Temperature (°C) | -20…+55 |
