Product Description
Description: Safety Relay • Mounting Type: Through Hole • Coil Voltage: 110VDC • Contact Configuration: 5A1B 6PST-5NO/1NC • Contact Rating (Current): 8 A • Switching Voltage: 400VAC - Max • Features: Sealed - Flux Protection • Termination Style: PC Pin
| Product Information | Resources |
|
|
RoHS Compliant| Specifications |
| Product Attribute | Attribute Value |
| Mounting Type | Through Hole |
| Coil Voltage | 110VDC |
| Contact Configuration | 5A1B 6PST-5NO/1NC |
| Contact Rating (Current) | 8 A |
| Switching Voltage | 400VAC - Max |
| Features | Sealed - Flux Protection |
| Termination Style | PC Pin |
| Must Operate Voltage | 82.5 VDC |
| Must Release Voltage | 11 VDC |
| Operate Time | 10 ms |
| Release Time | 4 ms |
| Operating Temperature | -40°C ~ 70°C |
| Contact Material | Silver Nickel (AgNi), Gold (Au) |
| Series Features |
| TYPE 50.16 - FORCIBLY GUIDED CONTACTS RELAY 8A |
| Series Description: Type 50.16 relays for printed circuit with forcibly guided contacts, according to EN 61810 (ex EN 50205) Type A. Relay for safety applications, 6 contacts, 8 A (4 NO + 2 NC) or (5 NO +1 NC). Contact AgSnO2 + Au |
|
