To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Finder |
| Manufacturer Product Number | 58.34.8.230.0060SPA |
| Description | Power Relay; 4C 4PDT; 7 A; 230VAC; Non Latching; DIN Rail; Screw Terminal |
| Datasheet | Download Datasheet |
The Finder 58.34.8.230.0060SPA is a power relay with 4C 4PDT contacts, rated 7 A and switching up to 250VAC, driven by a 230VAC coil and drawing 6 mA.
It has DIN Rail mounting and screw terminals, contacts in AgNi and is supplied with green LED + varistor, plastic retaining clip.
| Category | |
| Manufacturer | Finder |
| Model | 58.34 |
| Mounting Type | DIN Rail |
| Coil Voltage | 230VAC |
| Contact Configuration | 4C 4PDT |
| Contact Rating (A) | 7 |
| Switching Voltage | 250VAC - Max |
| Contact Material | AgNi |
| Coil Current (mA) | 6 |
| Coil Resistance (ohm) | 17000 |
| Coil Type | Non Latching |
| Termination Style | Screw Terminal |
| Must Operate Voltage | 184 V |
| Must Drop-Out Voltage | 46 V |
| Features | Green LED + varistor, Plastic retaining clip |
| Number of Poles | 4 |
| Operate Time (ms) | 11 |
| Release Time (ms) | 3 |
| Operating Temperature (°C) | -40...+70 |
| Rated Load AC1 (VA) | 1750 |
| Mechanical Life (cycles) | 20,000,000 |
| Electrical Life (cycles) | 150,000 |
