Product Description
Description: Power Relay • Mounting Type: DIN Rail • Coil Voltage: 120VAC • Contact Form: 4C 4PDT • Contact Rating (Current): 7 A • Coil Type: Non Latching • Features: Lighted Indicator, Mechanical Indicator • Termination Style: Screw Terminal • Relay Type: Interface Module
| Product Information | Resources |
|
|
RoHS Compliant| Specifications |
| Product Attribute | Attribute Value |
| Mounting Type | DIN Rail |
| Coil Voltage | 120VAC |
| Contact Form | 4C 4PDT |
| Contact Rating (Current) | 7 A |
| Switching Voltage | 250VAC - Max |
| Load - Max Switching | 1750VA |
| Coil Current | 97 mA |
| Coil Type | Non Latching |
| Features | Lighted Indicator, Mechanical Indicator |
| Termination Style | Screw Terminal |
| Must Operate Voltage | 9.6 VAC |
| Must Release Voltage | 24 VAC |
| Operate Time | 11 ms |
| Release Time | 3 ms |
| Operating Temperature | -40°C ~ 70°C |
| Contact Material | Silver Nickel (AgNi) |
| Approval Agency | CE, CSA, cURus, EAC, RINA, UKCA, VDE |
| Relay Type | Interface Module |
| Series Features |
| TYPE 58.34 - RELAY INTERFACE MODULE 7A |
| Series Description: Type 58.34 is a relay interface module, 4 CO 7 A, with screw terminals, 27 mm wide. For interfacing with PLC systems. Available Atex compliant version (HazLoc Class I Div. 2 Groups A, B, C, D T5 compliant): 58.34-x0xx, 4 CO 6 A, with scren termin |
|
