Product Description
Description: Power Relay • Mounting Type: Socketable • Coil Voltage: 72VDC • Contact Configuration: 4C 4PDT • Contact Rating (Current): 7 A • Coil Type: Non Latching • Features: - • Termination Style: Plug In
| Product Information | Resources |
|
|
RoHS Compliant| Specifications |
| Product Attribute | Attribute Value |
| Mounting Type | Socketable |
| Coil Voltage | 72VDC |
| Contact Configuration | 4C 4PDT |
| Contact Rating (Current) | 7 A |
| Switching Voltage | 250VAC - Max |
| Load - Max Switching | 1750VA |
| Coil Current | 15 mA |
| Coil Type | Non Latching |
| Features | - |
| Termination Style | Plug In |
| Seal Rating | - |
| Must Operate Voltage | 50.4 VDC |
| Must Release Voltage | 7.2 VDC |
| Operate Time | 11 ms |
| Release Time | 3 ms |
| Operating Temperature | -40°C ~ 85°C |
| Contact Material | Silver Nickel (AgNi) |
| Approval Agency | CCC, CE, CSA, cURus, EAC, ENEC, RINA, UKCA, VDE |
| Series Features |
| TYPE 55.34T - RELAY FOR RAILWAY APPLICATIONS 7A |
| Series Description: Type 55.34T relay for railway applications, 4 CO, 7A, for use with 94 Series sockets. |
|
