Product Description
Description: Power Relay • Mounting Type: DIN Rail • Coil Voltage: 230VAC • Contact Form: 1C SPDT • Contact Rating (Current): 10 A • Coil Type: Non Latching • Features: Lighted Indicator, Varistor • Termination Style: Spring Terminal • Relay Type: Interface Module
| Product Information | | Resources |
| Manufacturer | Finder | | Product Category | Relay | | Product Sub Category | Power Relay | | Series | 4C Series | | Model | Type 4C.P1 |
| | |
Product Attribute
| Attribute Value
|
| Mounting Type | DIN Rail |
| Coil Voltage | 230VAC |
| Contact Form | 1C SPDT |
| Contact Rating (Current) | 10 A |
| Switching Voltage | 440VAC - Max |
| Load - Max Switching | 4400VA |
| Coil Current | 5 mA |
| Coil Type | Non Latching |
| Features | Lighted Indicator, Varistor |
| Termination Style | Spring Terminal |
| Must Operate Voltage | 184 VAC |
| Must Release Voltage | 46 VAC |
| Operate Time | 15 ms |
| Release Time | 5 ms |
| Operating Temperature | -40°C ~ 70°C |
| Contact Material | Silver Nickel (AgNi) |
| Relay Type | Interface Module |
| TYPE 4C.P1 - RELAY INTERFACE MODULES 10A |
| Series Description: Type 4C.P1 Relay Interface Modules, 1 CO 10 A, Push-in terminals, 15.8 mm wide. For interfacing with PLC systems. |
- AC or DC coil
- Coil Indication and EMC suppression module
- Identification label
- UL Listing (relay/socket/jumper link)
- 35 mm rail (EN 60715) mounting
- Cadmium-free contacts
|
RoHS Compliant
