Product Description
Description: Power Relay • Mounting Type: DIN Rail • Coil Voltage: 24VDC • Contact Configuration: 2C DPDT • Contact Rating (Current): 8 A • Switching Voltage: 440VAC - Max • Coil Current: 20 mA • Coil Type: Non Latching • Features: Diode, Lighted Indicator • Termination Style: Screw Terminal
| Product Information | | Resources |
| Manufacturer | Finder | | Product Category | Relays | | Product Sub Category | Power Relay | | Series | 4C Series | | Model | Type 4C.02 |
| | |
Product Attribute
| Attribute Value
|
| Mounting Type | DIN Rail |
| Coil Voltage | 24VDC |
| Contact Configuration | 2C DPDT |
| Contact Rating (Current) | 8 A |
| Switching Voltage | 440VAC - Max |
| Coil Current | 20 mA |
| Coil Type | Non Latching |
| Features | Diode, Lighted Indicator |
| Termination Style | Screw Terminal |
| Must Operate Voltage | 17.5 VDC |
| Must Release Voltage | 4.8 VDC |
| Operate Time | 10 ms |
| Release Time | 10 ms |
| Operating Temperature | -40°C ~ 70°C |
| Contact Material | Silver Nickel (AgNi), Gold (Au) |
| Relay Type | Interface Module |
| TYPE 4C.02 - RELAY INTERFACE MODULES 8A |
| Series Description: Type 4C.02 Relay Interface Modules, 2 CO 8 A, screw terminals, 15.8 mm wide. For interfacing with PLC systems. |
- AC or DC coil
- Coil Indication and EMC suppression module
- Identification label
- UL Listing (relay/socket/jumper link)
- 35 mm rail (EN 60715) mounting
- Cadmium-free contacts
|
RoHS Compliant
