Product Description
Description: Power Relay • Mounting Type: DIN Rail • Coil Voltage: 125VDC • Contact Form: 2C DPDT • Contact Rating (Current): 10 A • Coil Type: Non Latching • Features: Diode, Lighted Indicator • Termination Style: Screw Terminal • Relay Type: Interface Module
| Product Information | Resources |
|
|
RoHS Compliant| Specifications |
| Product Attribute | Attribute Value |
| Mounting Type | DIN Rail |
| Coil Voltage | 125VDC |
| Contact Form | 2C DPDT |
| Contact Rating (Current) | 10 A |
| Switching Voltage | 400VAC - Max |
| Load - Max Switching | 4000VA |
| Coil Current | 4 mA |
| Coil Type | Non Latching |
| Features | Diode, Lighted Indicator |
| Termination Style | Screw Terminal |
| Must Operate Voltage | 91 VDC |
| Must Release Voltage | 12.5 VDC |
| Operate Time | 12 ms |
| Release Time | 12 ms |
| Operating Temperature | -40°C ~ 70°C |
| Contact Material | Silver Nickel (AgNi) |
| Relay Type | Interface Module |
| Approval Agency | CE, CSA, cURus EAC, NF, RINA, UKCA, VDE |
| Series Features |
| TYPE 48.62 - RELAY INTERFACE MODULE 10A |
| Series Description: Type 48.62 relay interface module with 2 CO 10A contacts and screw terminals.This product is 15.8 mm wide, and an ideal interface for PLC and electronic systems. |
|
