Product Description
Description: Power Relay • Mounting Type: DIN Rail • Coil Voltage: 110VAC • Contact Configuration: 2C DPDT • Contact Rating (Current): 8 A • Switching Voltage: 400VAC - Max • Coil Current: 10.1 mA • Coil Type: Non Latching • Features: Lighted Indicator, Varistor • Termination Style: Screw Terminal
| Product Information | Resources |
|
|
RoHS Compliant| Specifications |
| Product Attribute | Attribute Value |
| Mounting Type | DIN Rail |
| Coil Voltage | 110VAC |
| Contact Configuration | 2C DPDT |
| Contact Rating (Current) | 8 A |
| Switching Voltage | 400VAC - Max |
| Coil Current | 10.1 mA |
| Coil Type | Non Latching |
| Features | Lighted Indicator, Varistor |
| Termination Style | Screw Terminal |
| Must Operate Voltage | 88 VAC |
| Must Release Voltage | 22 VAC |
| Operate Time | 7 ms |
| Release Time | 4 ms |
| Operating Temperature | -40°C ~ 70°C |
| Contact Material | Silver Nickel (AgNi) |
| Relay Type | Interface Module |
| Series Features |
| TYPE 48.52 - RELAY INTERFACE MODULE 8A |
| Series Description: Type 48.52 Relay Interface Module, 2 CO 8 A, screw terminals, 15.8 mm wide. For energy applications. Breaking power on inductive DC load (L/R = 40 ms) 110 V = 0.5 A 220 V = 0.2 A |
|
