Product Description
Description: Power Relay • Mounting Type: Socketable • Coil Voltage: 24VDC • Contact Configuration: 1C SPDT • Contact Rating (Current): 16 A • Switching Voltage: 440VAC - Max • Coil Current: 20 mA • Coil Type: Non Latching • Features: - • Termination Style: Plug In, Quick Connect - 0.187" (4.7mm)
Product Information | Resources |
|
|
Specifications |
Product Attribute | Attribute Value |
Mounting Type | Socketable |
Coil Voltage | 24VDC |
Contact Configuration | 1C SPDT |
Contact Rating (Current) | 16 A |
Switching Voltage | 440VAC - Max |
Coil Current | 20 mA |
Coil Type | Non Latching |
Features | - |
Termination Style | Plug In, Quick Connect - 0.187" (4.7mm) |
Must Operate Voltage | 17.5 VDC |
Must Release Voltage | 4.8 VDC |
Operate Time | 15 ms |
Release Time | 5 ms |
Operating Temperature | -40°C ~ 70°C |
Contact Material | Silver Tin Oxide (AgSnO) |
Relay Type | General Purpose |
Series Features |
46 SERIES Miniature Industrial relays 8 - 16A |
Series Description: The 46 Series comprises industrial power relays with the following features (according to Type): |
|
