Product Description
Description: Power Relay • Mounting Type: Through Hole • Coil Voltage: 24VDC • Contact Configuration: 1A SPST-NO • Contact Rating (Current): 16 A • Coil Type: Non Latching • Termination Style: PC Pin • Seal Rating: Sealed - Flux Protection
| Product Information | Resources |
|
|
RoHS Compliant| Specifications |
| Product Attribute | Attribute Value |
| Mounting Type | Through Hole |
| Coil Voltage | 24VDC |
| Contact Configuration | 1A SPST-NO |
| Contact Rating (Current) | 16 A |
| Switching Voltage | 400VAC - Max |
| Load - Max Switching | 6400VA |
| Coil Current | 16.7 mA |
| Coil Type | Non Latching |
| Termination Style | PC Pin |
| Seal Rating | Sealed - Flux Protection |
| Must Operate Voltage | 16.8 VDC |
| Must Release Voltage | 3.6 VDC |
| Operate Time | 8 ms |
| Release Time | 6 ms |
| Operating Temperature | -40°C ~ 85°C |
| Contact Material | Silver Tin Oxide (AgSnO) |
| Approval Agency | cURus, EAC, ENEC, RINA, VDE |
| Series Features |
| TYPE 41.61 - LOW PROFILE PCB RELAY 16A |
| Series Description: Type 41.61 low profile relay with 1 Pole 16 A CO contacts (5.0 mm pin pitch) for PCB mount, direct or via PCB socket. Available Type 41.61.6.xxx, 1 pole, 16A, PCB direct mount. |
|
