Product Description
Description: Power Relay • Mounting Type: Through Hole • Coil Voltage: 5VDC • Contact Form: 2C DPDT • Contact Rating (Current): 16 A • Coil Type: Latching, Dual Coil • Termination Style: PC Pin • Seal Rating: -
| Product Information | Resources |
|
|
RoHS Compliant| Specifications |
| Product Attribute | Attribute Value |
| Mounting Type | Through Hole |
| Coil Voltage | 5VDC |
| Contact Form | 2C DPDT |
| Contact Rating (Current) | 16 A |
| Switching Voltage | 400VAC - Max |
| Load - Max Switching | 3200VA |
| Coil Current | 130 mA |
| Coil Type | Latching, Dual Coil |
| Termination Style | PC Pin |
| Seal Rating | - |
| Must Operate Voltage | 3.5 VDC |
| Must Release Voltage | 0.75 VDC |
| Operate Time | 8 ms |
| Release Time | 6 ms |
| Operating Temperature | -40°C ~ 85°C |
| Contact Material | Silver Tin Oxide (AgSnO) |
| Approval Agency | cURus, EAC, ENEC, RINA, VDE |
| Series Features |
| TYPE 41.52 - LOW PROFILE PCB RELAYS 8A |
| Series Description: Type 41.52 low profile PCB relays, 2 CO 8 A (pin pitch 5.0 mm) for direct PCB mounting or with 93 and 95 Series sockets. Suitable for direct mount on a printed circuit or via a socket, and for mount on a 35 mm rail (EN 60715) on sockets with box clamp or |
|
