Product Description
Description: Power Relay • Mounting Type: Through Hole • Coil Voltage: 120VAC • Contact Configuration: 1C SPDT • Contact Rating (Current): 16A • Coil Type: Non Latching • Termination Style: PC Pin • Seal Rating: Sealed - Flux Protection • Contact Material: -
| Product Information | Resources |
|
|
RoHS Compliant| Specifications |
| Product Attribute | Attribute Value |
| Mounting Type | Through Hole |
| Coil Voltage | 120VAC |
| Contact Configuration | 1C SPDT |
| Contact Rating (Current) | 16A |
| Switching Voltage | 400VAC - Max |
| Load - Max Switching | 6400VA |
| Coil Current | 8.4 mA |
| Coil Type | Non Latching |
| Termination Style | PC Pin |
| Seal Rating | Sealed - Flux Protection |
| Must Operate Voltage | 96 VAC |
| Must Release Voltage | 24 VAC |
| Operate Time | 7 ms |
| Release Time | 3 ms |
| Operating Temperature | -40°C ~ 85°C |
| Contact Material | - |
| Approval Agency | CCC, CSA, cURus, EAC, ENEC, RINA, VDE |
