To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Finder |
| Manufacturer Product Number | 40.52.7.018.0000 |
| Description | Power Relay; 2C DPDT; 8 A; 18VDC; Non Latching; Through Hole, Socketable |
| Datasheet | Download Datasheet |
The Finder 40.52.7.018.0000 is a power relay with 2C DPDT contacts, rated 8 A and switching up to 400VAC, driven by a 18VDC coil and drawing 27.7 mA.
It has Through Hole, Socketable mounting and PC Pin, Plug In terminals and contacts in AgNi.
| Category | |
| Manufacturer | Finder |
| Model | 40.52 |
| Mounting Type | Through Hole, Socketable |
| Coil Voltage | 18VDC |
| Contact Configuration | 2C DPDT |
| Contact Rating (A) | 8 |
| Switching Voltage | 400VAC - Max |
| Contact Material | AgNi |
| Coil Current (mA) | 27.7 |
| Coil Resistance (ohm) | 650 |
| Coil Type | Non Latching |
| Termination Style | PC Pin, Plug In |
| Must Operate Voltage | 13.2 V |
| Must Drop-Out Voltage | 1.8 V |
| Seal Rating | Sealed - Flux Protection |
| Number of Poles | 2 |
| Pin Pitch (mm) | 5 |
| Operate Time (ms) | 12 |
| Release Time (ms) | 4 |
| Operating Temperature (°C) | -40...+85 |
| Rated Load AC1 (VA) | 2000 |
| Mechanical Life (cycles) | 10,000,000 |
| Electrical Life (cycles) | 100,000 |
