To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Finder |
| Manufacturer Product Number | 22.32.0.230.4320 |
| Description | Modular Contactor; 25 A; 2A DPST-NO; (230...240)V AC / 220 V DC |
| Datasheet | Download Datasheet |
The Finder 22.32.0.230.4320 is a 17.5 mm modular contactor with 2A DPST-NO contacts and rated 25 A, driven by a (230...240)V AC / 220 V DC coil.
Its AgSnO2 contacts suit lamp and high inrush current loads.
It takes auxiliary contact module 022.33 (2 NO) or 022.35 (1 NO + 1 NC).
It has DIN Rail mounting and screw terminals, contacts in AgSnO2 and is supplied with mechanical indicator and LED.
| Category | |
| Manufacturer | Finder |
| Model | 22.32 |
| Number of Poles | 2 |
| Contact Configuration | 2A DPST-NO |
| Contact Rating (A) | 25 |
| Rated Voltage | 250 V AC (440 V AC max) |
| Contact Material | AgSnO2 |
| Load Type | Lamp and high inrush current loads |
| Coil Voltage | (230...240)V AC / 220 V DC |
| Features | Mechanical indicator and LED |
| Auxiliary Module | 022.33 (2 NO) or 022.35 (1 NO + 1 NC) |
| Mechanical Life | 2,000,000 cycles (30,000 cycles) |
| Operate/Release Time | 30/20 ms |
| Module Width (mm) | 17.5 |
| Mounting Type | DIN Rail |
| Termination Style | Screw Terminal |
| Operating Temperature (°C) | -25...+50 |
| Approvals | CE, cULus, IMQ, RINA, Lloyd's Register, EAC |
