Product Description
Description: Power Contactor • Coil Voltage: 230 VAC/DC • Rated thermo-current lth (in AC):: 25 A • Contact Configuration: 4B 4PST-NC • Mounting: Din Rial
| Product Information | | Resources |
| Manufacturer | ELKO | | Product Category | Contactor | | Product Sub Category | Power Contactor | | Series | VS425 |
| | |
Product Attribute
| Attribute Value
|
| Coil Voltage | 230 VAC/DC |
| Rated thermo-current lth (in AC): | 25 A |
| Contact Configuration | 4B 4PST-NC |
| Mounting | Din Rial |
| Rated insulation voltage (Ui): | 440 V |
| Coil permanent supply +/- 10 %: | 2.6 VA/2.6 W |
| Coil gear supply +/- 10 %: | 2.6 VA/2.6 W |
| Mounting side-by-side: | max. 2 contactors |
| Operational temperature: | -5 to +55 °C (23 to 131 °F) |
| Storing temperature: | -30 to +80 °C (-22 to 176 °F) |
| Standards: | IEC 60947-4-1, IEC 60947-5-1, IEC 61095, EN 60947-4-1, EN 60947-5-1, EN 61095, EN 60947-1 |
| VS120, VS220, VS420, VS425, VS440, VS463 |
| Series Description: Installation contactors |
- For switching electric circuits, especially for resistave loads and threephase induction motors: number of contacts VS120: 1 / number of contacts VS220: 2 / number of contacts VS420, VS425, VS440, VS463: 4
- It is produced in confi guration of switching and breaking contacts: VS120: 10, 01 / VS220: 20, 11, 02 / VS420: 40, 31 / VS425: 40, 31, 22, 04 / VS440: 40, 31, 22, 04 / VS463: 40, 31, 22
- Protection IP20 - on request we deliver covers that ensure protection IP40 for all terminals.
- DIN rail or panel mounting.
|
RoHS Compliant
