| Manufacturer | Curtis Industries |
| Manufacturer Product Number | OK435/10 FV |
| Description | Euro Terminal Strip; 10-pos; 14.5mm (0.571"); 65A; 600V |
| Datasheet | Download Datasheet |
The Curtis Industries OK435/10 FV is a 10-position Euro-style terminal strip on a 14.5mm (0.571") pitch. It is UL rated 65A at 600V with 6 AWG wire, and IEC rated 76A at 450V with 16mm² wire. It is 5.56" (141.2mm) long.
The body is natural polyamide PA6.6 (nylon), 15% glass fiber, rated 150°C (302°F) max, UL 94V-0. Inserts are nickel-plated brass. Screws are zinc-plated steel. Tightening torque: Min. 1.2 Nm (10 in-lbs). UL file E73420.
| Category | |
| Manufacturer | Curtis Industries |
