To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Curtis Industries |
| Manufacturer Product Number | OK434/11 FV-HLP |
| Description | Euro Terminal Strip; 11-pos; 12.0mm (0.472"); 30A; 600V; Yes |
| Datasheet | Download Datasheet |
The Curtis Industries OK434/11 FV-HLP is a 11-position Euro-style terminal strip on a 12.0mm (0.472") pitch. It is UL rated 30A at 600V with 10 AWG wire, and IEC rated 41A at 450V with 6mm² wire. It is 5.01" (127.3mm) long.
The body is natural polyamide PA6.6 (nylon), 25% glass fiber, rated 150°C (302°F) max, UL 94V-0. Inserts are nickel-plated brass, with stainless steel plate. Screws are zinc-plated steel. Tightening torque: Min. 1.1 Nm (10 in-lbs). It has a wire protector under each screw. UL file E73420.
| Category | |
| Manufacturer | Curtis Industries |
