To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Curtis Industries |
| Manufacturer Product Number | OK433/2 FV-F |
| Description | Euro Terminal Strip; 2-pos; 10.0mm (0.394"); 20A; 600V |
| Datasheet | Download Datasheet |
The Curtis Industries OK433/2 FV-F is a 2-position Euro-style terminal strip on a 10.0mm (0.394") pitch. It is UL rated 20A at 600V with 12 AWG wire, and IEC rated 32A at 450V with 4mm² wire. It is 0.65" (16.4mm) long.
The body is natural polyamide PA6.6 (nylon), 25% glass fiber, rated 150°C (302°F) max, UL 94V-0. Inserts are nickel-plated brass. Screws are zinc-plated steel. Tightening torque: Min. 0.8 Nm (7 in-lbs). UL file E73420.
| Category | |
| Manufacturer | Curtis Industries |
