To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Curtis Industries |
| Manufacturer Product Number | OK431/8 FV |
| Description | Euro Terminal Strip; 8-pos; 8.0mm (0.315"); 15A; 600V |
| Datasheet | Download Datasheet |
The Curtis Industries OK431/8 FV is a 8-position Euro-style terminal strip on a 8.0mm (0.315") pitch. It is UL rated 15A at 600V with 14 AWG wire, and IEC rated 24A at 450V with 2.5mm² wire. It is 2.43" (61.7mm) long.
The body is natural polyamide PA6.6 (nylon), 25% glass fiber, rated 150°C (302°F) max, UL 94V-0. Inserts are nickel-plated brass. Screws are zinc-plated steel. Tightening torque: Min. 0.6 Nm (5 in-lbs). UL file E73420.
| Category | |
| Manufacturer | Curtis Industries |
| Number of Positions | 8 |
| Pitch | 8.0mm (0.315") |
| Current Rating | 15A |
| Voltage Rating | 600V |
| Wire Range | 14 AWG |
| IEC Current Rating | 24A |
| IEC Voltage Rating | 450V |
| IEC Wire Range | 2.5mm² |
| Housing Material | Natural Polyamide PA6.6 (Nylon), 25% Glass Fiber |
| Rated Temperature | 150°C (302°F) |
| Flammability Rating | UL 94V-0 |
| Insert Material | Brass, Nickel-Plated |
| Screw Material | Steel, Zinc-Plated |
| Tightening Torque | Min. 0.6 Nm (5 in-lbs) |
| Length | 2.43" (61.7mm) |
| UL File | E73420 |
