To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Curtis Industries |
| Manufacturer Product Number | OK431/5 FV |
| Description | Euro Terminal Strip; 5-pos; 8.0mm (0.315"); 15A; 600V |
| Datasheet | Download Datasheet |
The Curtis Industries OK431/5 FV is a 5-position Euro-style terminal strip on a 8.0mm (0.315") pitch. It is UL rated 15A at 600V with 14 AWG wire, and IEC rated 24A at 450V with 2.5mm² wire. It is 1.48" (37.7mm) long.
The body is natural polyamide PA6.6 (nylon), 25% glass fiber, rated 150°C (302°F) max, UL 94V-0. Inserts are nickel-plated brass. Screws are zinc-plated steel. Tightening torque: Min. 0.6 Nm (5 in-lbs). UL file E73420.
| Category | |
| Manufacturer | Curtis Industries |
