To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Curtis Industries |
| Manufacturer Product Number | 431610-15-0 |
| Description | Term Blk; 15-pos; 0.438"; Ext Pin; Zinc Scr; 8-32 Scr; No Mtg Ends; 20A; 300V |
| Datasheet | Download Datasheet |
The Curtis Industries 431610-15-0 is a 15-position single-row barrier terminal block on a 0.438" (11.11mm) pitch, with dual-wall barriers. It is rated 20A at 300V and takes 12-22 AWG wire.
It is a base-mount block without mounting ends. Wires land on 8-32 zinc-plated steel combo-head screws. Underneath it has extended PC / wire-wrap pins.
The housing is reinforced PBT polyester, rated UL 94V-0 with a 130°C (266°F) UL temperature index. Terminals are tin-plated brass. Tighten the screws to 9 in-lbs.
| Category | |
| Manufacturer | Curtis Industries |
