To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Carlo Gavazzi |
| Manufacturer Product Number | CGMS-6A-24-10 |
| Description | Contactor; 6 A; CGMS-6A; 3A 3PST-NO; 24 V AC 50/60 Hz; Screw Terminal; 1 NO |
| Datasheet | Download Datasheet |
The Carlo Gavazzi CGMS-6A-24-10 is a 3-pole mini contactor with 3A 3PST-NO main contacts, rated 20 A (AC-1) and 6 A (AC-3), with a 24 V AC 50/60 Hz coil.
Auxiliary contacts: 1 NO. IEC motor rating 1.5 kW @ 220–240 V, 2.2 kW @ 380–440 V, 3 kW @ 500–550 V, 3 kW @ 690 V. NEMA size 00, UL continuous current 20 A. It has screw terminals. Rated voltage 690 V AC; operating temperature -5 to +40 °C. Approvals: CE, UL, cUL.
| Category | |
| Manufacturer | Carlo Gavazzi |
| Model | CGMS-6A |
| Number of Poles | 3 |
| Contact Configuration | 3A 3PST-NO |
| Contact Rating (A) | 20 |
| Rated Voltage | 690 V AC |
| Rated Current AC3 (A) | 6 |
| Coil Voltage | 24 V AC 50/60 Hz |
| Termination Style | Screw Terminal |
| Operating Temperature | -5…+40 °C (-30…+65 °C) |
| Approvals | CE, UL, cUL |
| Auxiliary Contacts | 1 NO |
| Motor Rating kW | 1.5 kW @ 220–240 V, 2.2 kW @ 380–440 V, 3 kW @ 500–550 V, 3 kW @ 690 V |
| Coil Type | AC |
| NEMA Size | 00 |
| UL Continuous Current (A) | 20 |
