Product Description
Description: Photo-electric Sensors • Sensing Method: Distance-Settable (BGS) • Sensing Distance: 19.685" ~ 98.425" (500mm ~ 2500mm) • Voltage - Supply: 10V ~ 30V • Response Time: 2ms • Output Configuration: NPN/PNP • Light Source: Infrared (850nm) • Connection Method: Cable • Ingress Protection: IEC 60529 IP67 • Cable Length: 78.74" (2m) • Adjustment Type: -
| Product Information | | Resources |
| Manufacturer | Carlo Gavazzi | | Product Category | Sensor | | Product Sub Category | Photo-electric Sensors | | Series | |
| | |
Product Attribute
| Attribute Value
|
| Sensing Method | Distance-Settable (BGS) |
| Sensing Distance | 19.685" ~ 98.425" (500mm ~ 2500mm) |
| Voltage - Supply | 10V ~ 30V |
| Response Time | 2ms |
| Output Configuration | NPN/PNP |
| Light Source | Infrared (850nm) |
| Connection Method | Cable |
| Ingress Protection | IEC 60529 IP67 |
| Cable Length | 78.74" (2m) |
| Adjustment Type | - |
| Operating Temperature | -25°C ~ 55°C |
| Photoelectrics Background Suppression Type PD112CNB25BP.. |
Series Description: The PD112CNB25 sensor comesina112x45x25mm strong polycarbonate (PC) housing. The sensors are useful in applications where long range and high accuracy detection is required.
Robust housing, a sophisticated mechanical design and high power LED for excellent performance in harsh environments.
The sensor has a test input, for door mode, designed to remotely disable (mute) the emitter and thereby evaluate the sensor function from a door controller or e.g. a PLC. The output type is preset (NPN and PNP) with select- able switching function NO/ NC.
2 selectable modes are built in: Industrial for general automation and Door spe- cifically for control of doors & gates. |
- Range: 2500 mm
- Accurate & stable distance adjustment
- Modulated, infrared light 850 nm
- Supply voltage: 10 to 30 VDC
- Output: 200 mA, NPN or PNP preset
- Make or break switching function selectable
- Adjustable ON- / OFF delay, 1 16 sec.
- LED indication for output and power ON
- Protection: reverse polarity, short circuit and transients Cable and plug versions
- Excellent EMC performance
- Remote test feature (mute)
|
