Product Description
Description: Photo-electric Sensors • Sensing Method: Reflective, Diffuse • Sensing Distance: 19.685" (500mm) • Voltage - Supply: 10V ~ 30V • Response Time: 2ms • Output Configuration: NPN/PNP • Light Source: Infrared (850nm) • Connection Method: Cable • Ingress Protection: IP67 • Cable Length: - • Adjustment Type: Adjustable
| Product Information | Resources |
|
|
| Specifications |
| Product Attribute | Attribute Value |
| Sensing Method | Reflective, Diffuse |
| Sensing Distance | 19.685" (500mm) |
| Voltage - Supply | 10V ~ 30V |
| Response Time | 2ms |
| Output Configuration | NPN/PNP |
| Light Source | Infrared (850nm) |
| Connection Method | Cable |
| Ingress Protection | IP67 |
| Cable Length | - |
| Adjustment Type | Adjustable |
| Operating Temperature | -20°C ~ 60°C |
| Series Features |
| Photoelectrics Diffuse-reflective, Background Suppression Type PC50CNB50BA |
| Series Description: The PC50CNB. is a family of high accuracy background suppression sensors in a compact square 17 x 50 x 50 mm reinforced PC/ABS-housing. They are useful in applications where color indepen- dence or background suppression is neccessary. The long sensing range together with sensitivity adjustment gives a very flexible sensor. The DC types are with a tran- sistor output and the configu- ration is fully programmable (NPN, PNP, NO and NC). |
|
