Product Description
Description: Photo-electric Sensors • Sensing Method: Retroreflective • Sensing Distance: 118.110" (3m) • Voltage - Supply: 10V ~ 40V • Response Time: 3.2ms, 5ms • Output Configuration: NPN • Light Source: Infrared (880nm) • Connection Method: Cable • Ingress Protection: IP67 • Cable Length: 78.74" (2m) • Adjustment Type: Adjustable, 1-Turn Potentiometer
| Product Information | Resources |
|
|
| Specifications |
| Product Attribute | Attribute Value |
| Sensing Method | Retroreflective |
| Sensing Distance | 118.110" (3m) |
| Voltage - Supply | 10V ~ 40V |
| Response Time | 3.2ms, 5ms |
| Output Configuration | NPN |
| Light Source | Infrared (880nm) |
| Connection Method | Cable |
| Ingress Protection | IP67 |
| Cable Length | 78.74" (2m) |
| Adjustment Type | Adjustable, 1-Turn Potentiometer |
| Operating Temperature | -20°C ~ 60°C |
| Series Features |
| Photoelectrics Retro-reflective Type ER1830.PAS, DC, Metal-housing |
| Series Description: Retro-reflective photoelectric switch with extended range up to 3 m. Easily adjustable sensitivity with 270° potentiometer. LED output indication. Short M18 metal housing for heavy duty applications. IP 67. Easy mounting. DC and AC types, fully protected. |
|
