To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Carlo Gavazzi |
| Manufacturer Product Number | ICS08S30F01NOM5 |
| Description | Inductive Sensor; 1 mm; M8; NPN; NO; 10–36 V DC; M8 3-pin plug |
| Datasheet | Download Datasheet |
The Carlo Gavazzi ICS08S30F01NOM5 is an M8 threaded flush inductive proximity sensor with a 1 mm sensing range, NPN NO output and a 10–36 V DC supply.
Output current 200 mA. Power-on delay ≤ 20 ms. Indicator: yellow LED (x4). It has an M8 3-pin plug and a stainless steel AISI 304 housing. IP 67; operating temperature -25 to +80 °C (storage -30…+80).
| Category | |
| Manufacturer | Carlo Gavazzi |
| Model | ICS08 |
| Body Style | Cylindrical Threaded, short (30 mm thread) |
| Housing Diameter | M8 |
| Thread Size | M8 x 1 |
| Sensing Range | 1 mm |
| Sensing Face | Flush |
| Output Type | NPN |
| Output Function | NO |
| Supply Voltage | 10–36 V DC |
| Supply Current | ≤ 16 mA |
| Load Current | 200 mA |
| Voltage Drop | Max. 1.6 V DC @ 200 mA |
| Repeatability | ≤ 5%; temperature drift ≤ ±10% |
| Short Circuit Protection | Yes (short-circuit, reverse polarity, transients and overload) |
| Status Indicator | Yellow LED (x4) |
| Connection | M8 3-pin plug |
| Mounting Type | Flush mountable |
| Housing Material | Stainless steel AISI 304 |
| Protection Category | IP 67 |
| Operating Temperature (°C) | -25…+80 (storage -30…+80) |
| Dimensions | M8 x 40 mm |
| Response Time | Power-on delay ≤ 20 ms |
