To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Carlo Gavazzi |
| Manufacturer Product Number | IBS06SF02NC |
| Description | Inductive Sensor; 2 mm; Ø 6.5 mm; NPN; NC; 10–36 V DC; 2 m PVC cable |
| Datasheet | Download Datasheet |
The Carlo Gavazzi IBS06SF02NC is a Ø 6.5 mm flush inductive proximity sensor with a 2 mm sensing range, NPN NC output and a 10–36 V DC supply.
Output current ≤ 200 mA. Power-on delay ≤ 20 ms. Indicator: yellow LED. It has a 2 m PVC cable and a stainless steel AISI 304 housing. IP 67; operating temperature -25 to +80 °C (storage -30…+80).
| Category | |
| Manufacturer | Carlo Gavazzi |
| Model | IBS06 |
| Body Style | Cylindrical Smooth |
| Housing Diameter | Ø 6.5 mm |
| Sensing Range | 2 mm |
| Sensing Face | Flush |
| Output Type | NPN |
| Output Function | NC |
| Supply Voltage | 10–36 V DC |
| Supply Current | ≤ 16 mA |
| Load Current | ≤ 200 mA |
| Voltage Drop | Max. 1.6 V DC @ 200 mA |
| Repeatability | ≤ 5% |
| Short Circuit Protection | Yes |
| Status Indicator | Yellow LED |
| Connection | 2 m PVC cable |
| Housing Material | Stainless steel AISI 304 |
| Protection Category | IP 67 |
| Operating Temperature (°C) | -25…+80 (storage -30…+80) |
| Dimensions | Ø 6.5 x 31 mm |
| Response Time | Power-on delay ≤ 20 ms |
